”Scroll Gestures”-‘UiScrollable’ | How to perform “Simple Scroll” by using ‘UiScrollable’ Class

Please go through the below video for complete details:

Summary:

UiScrollable:

UiScrollable is a UiCollection and provides support for searching for items in a scrollable user interface (UI) elements. This class can be used with horizontally or vertically scrollable controls.

UiScrollable(UiSelector container)

UiScrollable is a UiCollection and as such requires a UiSelector to identify the container UI element of the scrollable collection.

Options-1:

ScrollIntoView (UiSelector selector)

Perform a scroll search for a UI element matching the UiSelector selector argument. See scrollDescriptionIntoView(String) and scrollTextIntoView(String).

Parameters

selector UiSelector selector

Returns

• true if the item was found and now is in view else false

Throws

UiObjectNotFoundException

Options-2:

ScrollTextIntoView (String text)

Performs a swipe up on the UI element until the requested text is visible or until swipe attempts have been exhausted. See setMaxSearchSwipes(int)

Parameters

text to look for

Returns

• true if item us found else false

Throws

UiObjectNotFoundException

Syntax:

("new UiScrollable(new UiSelector().scrollable(true))"+".scrollIntoView(new UiSelector().text(\"Tabs\"))"));

Example:

driver.findElement(AppiumBy.androidUIAutomator("new UiScrollable(new UiSelector().scrollable(true))"+
    ".scrollIntoView(new UiSelector().text(\"Tabs\"))"));

Code :

package demo;

import org.testng.annotations.AfterClass;
import org.testng.annotations.BeforeClass;
import org.testng.annotations.Test;

import io.appium.java_client.AppiumBy;
import io.appium.java_client.android.AndroidDriver;
import io.appium.java_client.android.nativekey.AndroidKey;
import io.appium.java_client.android.nativekey.KeyEvent;
import io.appium.java_client.android.options.UiAutomator2Options;
import java.net.*;
import java.time.Duration;

/**
 * Script Details - "Scroll Gestures” -‘UiScrollable’ | How to perform "Simple Scroll" by using 'UiScrollable' Class
 *
 * appium-java-client version: 9.3.0
 *
 * @author 'Ramesh Kodumuru' for AppiumGuide [appiumguide@gmail.com]
 */

public class ScrollDemo1 {

 private AndroidDriver driver;

 @BeforeClass
 public void setup() throws MalformedURLException {
  UiAutomator2Options cap=new UiAutomator2Options();
  cap.setPlatformName("android");
  cap.setAutomationName("uiautomator2");
  cap.setDeviceName("Pixel8Pro");


  driver = new AndroidDriver(new URL("http://127.0.0.1:4723"), cap);
  driver.manage().timeouts().implicitlyWait(Duration.ofSeconds(10));


 }

 @Test
 public void ScrollTest1() throws InterruptedException {

  driver.activateApp("io.appium.android.apis");

  driver.findElement(AppiumBy.accessibilityId("Views")).click();


  driver.findElement(AppiumBy.androidUIAutomator("new UiScrollable(new UiSelector().scrollable(true))"+
    ".scrollIntoView(new UiSelector().text(\"Tabs\"))"));

  Thread.sleep(3000);

  driver.findElement(AppiumBy.accessibilityId("Tabs")).click();

  Thread.sleep(3000);

  driver.pressKey(new KeyEvent(AndroidKey.BACK));

  Thread.sleep(3000);


  driver.findElement(AppiumBy.androidUIAutomator("new UiScrollable(new UiSelector().scrollable(true))"+
    ".scrollIntoView(new UiSelector().textContains(\"Animati\"))"));

  Thread.sleep(3000);


  driver.findElement(AppiumBy.accessibilityId("Animation")).click();




 }



 @AfterClass
 public void teardown() {

  if(driver!=null) {
   driver.quit();
   System.out.println("Test Execution Completed");
  }

 }

}

GitHub Link:
