Appium Concepts: How to Capture a “Screen Shot” by using in-built — “getScreenshotAs” method

1. getScreenshotAs(OutputType.FILE);

2. getScreenshotAs(OutputType.BASE64);

3. getScreenshotAs(OutputType.BYTES);

Please go through the below video for complete details:

Topic-1: Introduction on “getScreenshotAs” method

Method Details:

<X> X getScreenshotAs(OutputType<X> target) throws WebDriverException

Capture the screenshot and store it in the specified location.

For a W3C-conformant WebDriver or WebElement, this behaves as stated in W3C WebDriver specification.

For a non-W3C-conformant WebDriver, this makes a best effort depending on the browser to return the following in order of preference:

• Entire page
• Current window
• Visible portion of the current frame
• The screenshot of the entire display containing the browser

For a non-W3C-conformant WebElement extending TakesScreenshot, this makes a best effort depending on the browser to return the following in order of preference:

• The entire content of the HTML element
• The visible portion of the HTML element

Type Parameters:

X - Return type for getScreenshotAs.

Parameters:

target - target type

Returns:

Object in which is stored information about the screenshot.

Throws:WebDriverException - on failure.UnsupportedOperationException - if the underlying implementation does not support screenshot capturing.

Topic-2: — getScreenshotAs(OutputType.FILE).

//Screenshot based on outputtype file
  System.out.println("Screenshot based on outputtype file");
  scrFile=driver.getScreenshotAs(OutputType.FILE);
  targetFile=new File("outputtype_file"+".png");
  FileUtils.copyFile(scrFile, targetFile);

Topic-3: — getScreenshotAs(OutputType.BASE64).

//Screenshot based on outputtype Base64
  System.out.println("Screenshot based on outputtype Base64");
  byte[] byteArray;
  String scrFile1=driver.getScreenshotAs(OutputType.BASE64);
  FileOutputStream fos=new FileOutputStream("outputtype_base64"+".png");
  byteArray=Base64.getDecoder().decode(scrFile1);
  fos.write(byteArray);

Topic-4: — getScreenshotAs(OutputType.BYTES)

 Thread.sleep(3000);
  //Screenshot based on outputtype bytes
  System.out.println("Screenshot based on outputtype bytes");
  byte[] srcFile=driver.getScreenshotAs(OutputType.BYTES);
  targetFile=new File("outputtype_bytes"+".png");
  FileUtils.writeByteArrayToFile(targetFile, srcFile);

Java Code:

package com.appiumguide.appiumconcepts;

import org.apache.commons.io.FileUtils;
import org.openqa.selenium.OutputType;
import org.testng.annotations.AfterTest;
import org.testng.annotations.BeforeTest;
import org.testng.annotations.Test;
import io.appium.java_client.AppiumBy;
import io.appium.java_client.android.AndroidDriver;
import io.appium.java_client.android.options.UiAutomator2Options;
import java.io.File;
import java.io.FileOutputStream;
import java.io.IOException;
import java.net.*;
import java.time.Duration;
import java.util.Base64;

/**
 * Script Details - Appium Concepts - How to Capture a "Screen Shot" by using in-built - "getScreenshotAs" method
 *
 * appium-java-client version: 9.3.0
 *
 * @author 'Ramesh Kodumuru' for AppiumGuide [appiumguide@gmail.com]
 */

public class TakesScreenShotDemo {

 private AndroidDriver driver;

 File scrFile,targetFile;

 @BeforeTest
 public void setup() throws MalformedURLException {
  UiAutomator2Options cap=new UiAutomator2Options();
  cap.setPlatformName("android");
  cap.setAutomationName("uiautomator2");
  cap.setDeviceName("Pixel8Pro");


  driver = new AndroidDriver(new URL("http://127.0.0.1:4723"), cap);
  driver.manage().timeouts().implicitlyWait(Duration.ofSeconds(10));

 }
 @Test
 public void sampletest() throws IOException, InterruptedException {

  driver.activateApp("com.wdiodemoapp");
  //Screenshot based on outputtype file
  System.out.println("Screenshot based on outputtype file");
  scrFile=driver.getScreenshotAs(OutputType.FILE);
  targetFile=new File("outputtype_file"+".png");
  FileUtils.copyFile(scrFile, targetFile);

  driver.findElement(AppiumBy.androidUIAutomator("new UiSelector().text(\"Drag\")")).click();

  Thread.sleep(3000);
  //Screenshot based on outputtype bytes
  System.out.println("Screenshot based on outputtype bytes");
  byte[] srcFile=driver.getScreenshotAs(OutputType.BYTES);
  targetFile=new File("outputtype_bytes"+".png");
  FileUtils.writeByteArrayToFile(targetFile, srcFile);

  driver.findElement(AppiumBy.androidUIAutomator("new UiSelector().text(\"Swipe\")")).click();
  Thread.sleep(3000);

  //Screenshot based on outputtype Base64
  System.out.println("Screenshot based on outputtype Base64");
  byte[] byteArray;
  String scrFile1=driver.getScreenshotAs(OutputType.BASE64);
  FileOutputStream fos=new FileOutputStream("outputtype_base64"+".png");
  byteArray=Base64.getDecoder().decode(scrFile1);
  fos.write(byteArray);

 }

 @AfterTest
 public void teardown() {

  if(driver!=null) {
   driver.quit();
   System.out.println("Test Execution Completed");

  }

 }

}

GitHub Link:
